HPM100/AMC

5-Year Warranty

0.1-150 rpm

0.0002-65 mL/min

Optional pump head：

AMC

Online consultation

Download

Product Introduction
Technical Parameter
Pump Head Parameter
OSD
Qualification Certificate
Dimension
Video Tutorials

Product Introduction

The pump shell protection level is IP66, specially designed for industrial environments. It features 6 types of sealing structures that withstand extreme humidity and temperature conditions, ensuring long-term stable operation.
The intelligent control system supports both transferring and dispensing functions.
The 4.3-inch touch screen enables simplified operation, parameter configuration, and calibration.
Circuit isolation is achieved both inside and outside the external control interface.
Aluminum alloy body with excellent heat dissipation performance.
Three levels of permissions management function.

Technical Parameter

EMC Standard	IEC 61000-6-2/IEC 61000-6-4/IEC 61000-3-2/IEC 61000-3-3
Housing material	Aluminum alloy
Speed range	0.1-150 rpm
Speed adjustment resolution	0.01 rpm
Display	4.3-inch industrial-grade color LCD screen
Control modes	Touch screen, mechanical keypad, external control signal control, communication control
Working modes	Transferring mode, dispensing mode (Fixed volume, dispensing, speed dispensing)
Transferring mode	Continuous operation at set flow rate and speed
Dispensing mode	Dispensing:Set volume, time, repeat numbers, pause time Dispensing:Set volume, flow rate, repeat numbers, pause time Speed dispensing:Set speed (rpm), time, repeat numbers, pause time
Dispensing volume range	0.1ml-9999L
Dispensing time range	0.1s-9999h
Pause time range	0.5s-9999h
Repeat numbers	1-9999 times, 0 means unlimited times
Calibration	Automatic calibration after inputting actual running liquid volume
Back suction angle	0-360°
Communication interface	RS485
Communication protocol	Modbus protocol (RTU mode)
External control speed signal	0-5V, 0-10V, 4-20mA (optional)
External control signal input	Active switch signal (5-24V) controls start/stop, direction; Passive switch signal controls start/stop
Signal output	Open collector output operation status; 4-20mA output
Open cover to stop pump function	Prevent misoperation and effectively protect user safety
Three levels of permissions	Reasonable configuration of operation permissions
Drive dimension	274×160×221 mm (L×W×H)
Power supply	AC110-220V±10% 50/60Hz
Rated power	110W
Working environment	0-40°C
Drive weight	6.2kg
Relative humidity	<100%
Protection level	IP66

Pump Head Parameter

Drive	Pump Head	Tubing Size	Speed	Flow rate(mL/min)
HPM100	AMC1-AMC12(10)	ID: 0.13-3.17mm, Wall: 0.8-1mm	0.1-150rpm	0.0002-48
HPM100	AMC1-AMC12(6)	ID: 0.13-3.17mm, Wall: 0.8-1mm	0.1-150rpm	0.0002-65
