DF600 integrated filling system driven by a low-power servo motor. One controller controls 4 groups, each group with 4 filling units, totaling 16 units. Features a 4.3" true color touch screen display and YZ35 high-flow pump head. Filling accuracy: ±0.5-1%.
The touch screen allows presetting of filling volume, time, pause duration, copy quantities, and back suction angle. Dynamically displays working status, filling data, parameter settings, and system configuration. Includes intelligent calibration and micro-adjustment functions.
Industry applications: Pharmaceutical filling machines, pharmaceuticals, cosmetics, food, and beverage dispensing.
| Product Composition and Flow Rate Range |
| Drive | Pump Head | Housing material |
Tube clamp/ connector material |
Tubing | （Motor speed 0.1-600rpm） Flow rate range mL/min |
|
| Tubing size | ID×Wall thickness(mm) | |||||
| DF600 Plus IV | YZ35-PPS | PPS | PP | 26# | 6.4×3.3 | 0.69-4200 |
| 73# | 9.6×3.3 | 1.23-7400 | ||||
| 82# | 12.7×3.3 | 2-12000 | ||||
| Filling Volume Reference Parameter(Media is water) |
| Drive | Pump Head | Tubing | Filling Volume（mL） | Filling Time（s） | Accuracy（±%） | Output（pcs/min） | Motor Speed（rpm） |
| DF600 Plus IV | YZ35-PPS | 26# | 50 | 1 | 0.5 | 30 | 434.78 |
| 26# | 100 | 2 | 0.5 | 20 | 434.78 | ||
| 73# | 100 | 1.2 | 0.5 | 27 | 406.50 | ||
| 73# | 150 | 2 | 0.5 | 20 | 365.85 | ||
| 82# | 200 | 1.5 | 0.5 | 24 | 400.00 | ||
| 2*YZ35 | 26# | 100 | 1.2 | 0.5 | 27 | 203.25 | |
| 73# | 200 | 1.5 | 0.5 | 24 | 325.20 | ||
| 82# | 500 | 2 | 0.5 | 20 | 375.00 |
Back-suction angle
Calibration
Effective unit
Pump head and tubing setting and 3times filling demonstration
Speed knob demonstration
